BB30Z

s.n. 2631

Fabric: Kubicek Polyester

Deflation system: Slide Vent

Rotation vent

Technical parameters

What's included?

Our basic type of fabric recommended for smaller ride operations.

A fast deflation system capable of two modes of venting.

One of the fastest rotation speeds on the market.

Series: Z Series
Model: BB30Z
Passengers: Pilot + 2-3
Volume: 3 000 m³ (105)
No. of gores: 24
Maximum Take-off Weight (MTOW): 945 kg / 2 083 lbs
Minimum Landing Weight (MLW): 410 kg / 903 lbs
Diameter (at equator): 18.7 m / 61 ft
Height (mouth to top): 18.4 m / 60 ft
In-price envelope fabric: Kubicek Polyester
Recommended basket: K14, K17
Recommended burners
Approved baskets: K10C, K10S, K13, K13 JAP, K13C, K13S, K14, K17, K17 JAP, K19, K19L, K22, K23
Approved burners: Sirius
Ignis Plus - 2

Get in touch with our team for more details and price quote.
